CHOCOLATE COATING MACHINE YX-600/YX-800

Chocolate depositing Machine adopt to the newest concept of chocolate forming process.Different kinds of crispy rice,expansion meters,grains,nuts and other fruit are allowed by the design.

According to your product requirement, we can also tailor different forms of moulding,high quality and variety of moulding equipment.

Specifications:
Single Head Chocolate Depositing Machine can be used for the production of single color, two colors (left and right) and pastes central filling chocolates. It has fully automatic functions of moulds pre-heating, depositing, moulds vibrating, cooling, de-moulding and conveying, and adopts PLC control system.
Technical Parameters:
Depositing Type: Pneumatic (AIRTAC)/ Servo Motor (DELTA)
Production Capacity(SPEED): 6-15 pieces of moulds/minute
Number of Moulds: 280 pieces
Moulds Size: 510*200*30mm
Machine length :14.7m
cooling tunnel layers : 10 ,termperature 5-10C
output products conveyor length : 2m
PU belt width :490mm
Contactor :Siemens
One material hopper (2 sides for 2 different chocolate pastes) with 1 water temperature control system
Material: Stainless steel machine frame, material hopper, depositing head, vibrating table and machine cover
Voltage: 380V, 50Hz, 3 phases (able to customize)
Motor/Reducer: Dongba, breaker : Hengfu
Pneumatic Air Cylinder: AirTAC (5 pieces)
Temperature Controller mould: Delta
PLC and PLC control panel:Delta
sensor : Autonics ,
transducer (inverter): Delta
contactor :Siemens
Cooling System(refrigerator): Copeland 20Hp
Capacity (ton/class):0.4~1.5 , 0.4~1, 0.6~2.5 ,

Shanghai Panda Machinery Co., Ltd. is  a factory specialized in designing,manufacturing pastry&candy processing machinery &lines of biscuit, candy(hard candy, soft candy), cake, cookies, bread, chocolate. Panda Machinery have a factory of  4,000m² located  in Fengxian district, Shanghai

Thanks to our technical and development team with rich experiences for a dozen of years and more than 300 whole production lines, Panda Machinery is capable of executing on turn-key base with capacity ranging from 50kg/h to 2000kg/h for different varieties of biscuit, candy, cake, cookies, bread,chocolate.

Due to our continuous investment on R&D and upgrading in industrial application year by year, Panda Machinery had formed its own unique and beneficial characters in food designing and process technology.

All our production lines are manufactured strictly under guideline of ISO 9001:2015. With our high level management, Panda Machinery had awarded CE certificate for the biscuit production line (both soft and hard), soft and hard candy production line, cake production line and bread production line.

With the highly educated staff who obtained BA degree and Ph.D in majors of Food Engineering and packaging machinery, which allows Panda to design and manufacture better food processing machines, and provide high quality of technical training and after-sales services for our customers.

We are really a world market-orienated manufacturer. Till now, our products have been exported to USA, Canada, Poland, North Korea, Britain, Japan,Turkey, Kazakhstan, Ukraine, Russia, Albania, Costarica, Sri Lanka, Israel, Cyprus, Uzbekistan, Thailand, Egypt, India, Pakistan, Peru, Brazil,Argentina etc.

We have formed our own insight for biscuit and candy processing industry and our solutions are verified successfully for customers. Panda are always ready and expecting chances to serve you at home and abroad.
